Description
Model 50BR-137 is a 50 Ohm manual step attenuator in a benchtop enclosure. The attenuation range is 0 to 61dB by 0.1dB steps. It operates DC-100 MHz and is rated for 2 Watts average of RF input power. This attenuator assembly is constructed with a dual knob rotary attenuator and a single knob rotary attenuator that are connected in series with each other. There are a total of three manual knobs: 0.1dB step knob, 1dB step knob, and 10dB step knob. With all three knobs set to their maximum setting, a total attenuation setting of 61dB can be achieved. It is available with 50 Ohm coaxial RF connectors: BNC, N, SMA or TNC female. The two RF connectors are located on the rear panel.
